ml 3000
The Pioneer ML 3000 Commercial Lift
made in Australia

Made in Australia

Designed for commercial use disabled access

  • AS1735.16 compliant BCA 3.6 and 3.3

  • Automatic operation

  • Single or dual entry

  • Travel up to 4m (FFL to FFL)

  • Speed 0.15m/s

  • Pit depth requirement only 100mm

  • Overhead requirement: Shaft 2350mm, extra space required for hydraulic rams

  • Single phase 16A supply

  • The ML 3000 is custom built, driven by two direct acting oil hydraulic cylinders

  • The ML 3000 is perfect for applications where disability access is necessary with budgetary restraints

  • Self supporting structure able to be clad directly

  • Optional automation of swing doors

mariner 16
The Mariner 16 Commercial Lift
made in Australia

Made in Australia

Designed for commercial use disabled access, multi level

  • AS1735.16 compliant BCA 3.6 and 3.3

  • Automatic operation

  • Single or dual entry

  • Travel up to 7.15m (FFL to FFL)

  • Speed 0.19m/s

  • Pit depth requirement only 100mm

  • Overhead requirement 2300mm

  • Single phase 16A supply

  • Chain suspended 2:1 ratio hydraulic

  • Self supporting structure able to be clad directly

  • Optional automation of swing doors

  • Short lead times and quick to install

​

mobility access
The Orion C350 Commercial Lift
made in Australia

Made in Australia

Designed for commercial use disabled access, multi level

  • AS1735.16 compliant BCA 3.6 and 3.3

  • Automatic operation with automatic sliding doors

  • Doors 2 panel sliding left or right 900 x 2000mm

  • Single or dual entry

  • Travel up to 7.15m (FFL to FFL)

  • Speed 0.19m/s

  • Pit depth requirement only 150mm

  • Overhead requirement only 2350mm

  • Single phase 32A supply

  • Chain suspended 2:1 ratio hydraulic

  • Self supporting structure able to be clad directly if selected

  • Short lead times and quick to install

Anchor 1
The Easy Lift and The Happy Lift

Commercial grade lifts for general and disabled use, multi level

  • Hydraulic or gearless traction drive

  • Carrying capacity from 250 kg to 1500 kg

  • AS 1735.16 compliant BCA 3.6 and 3.3

  • AS 1735.1 or AS 1735.2 compliant part 12

  • Configured to client requirements

  • Short assembly time in all types of buildings

  • Concrete shaft or self supporting structures

  • High quality components, high performance over time

  • Made in EU

​

Anchor 2
 Vertical Platform Lifts

  • Carrying capacity up to 400kg

  • Platform size up to 1100mm x 1400mm

  • Rise from 0.6m to 1.8m

  • Control cabinet within the lift guide shroud

  • Belt drive

  • Internal or external use

  • 240V 20A supply requirement

  • Built to comply with AS1735.14 and BCA 3.6

  • Requires concrete base and solidly built deck edge

  • Competitive pricing
